The ATV-towable OPC503 Chipper Shredder features a KOHLER® Command PRO® CH270 7 HP 208 cc engine with high-strength double-edge cutting blades for extended sharpness. Its direct drive system efficiently processes trees, branches, leaves, and compost. Additional features include a 4-stage cyclonic air filter, auto-blade feeding, removable key lock shutoff, and ATV-locking off-road tires.
Specification
Certification(S)
EPA Phase III, CARB Phase III
Material
Steel
Material Finish
UV Powder Coated
Color
Black, Orange
Wheels
145/70-6 13.75 in (34.9 cm) O.D. x 5.25 in (13.3 cm)
Coupler
2 in (5.08 cm) ball
Wheelbase
28 in (71.1 cm)
Maximum Speed
Off-road only and max speed 15 mph (24 km/h)
Engine/Motor
KOHLER® Command PRO® CH270 7 HP 208 cc gas engine
Engine/Motor Maximum Torque
10.7 ft/lb (14.5 Nm)
Cutters
Double-edge blades and hammer shredders
Handle Height
48 in (121.9 cm)
Maximum Feed Chute Capacity
Ø3 in (Ø7.6 cm)
Maximum Top-Loading Hopper Capacity
Ø3/8 in (Ø0.95 cm)
Expulsion Chute
Vertically adjustable deflection
Assembled Dimensions (LxWxH)
63 in x 32 in x 43 in (160 cm x 81.3 cm x 109.2 cm)
Assembled Weight
170 lb (77.1 kg)
Disclaimer
Product appearance and specifications are subject to change, Off-road only and max speed 15 mph (24 km/h)
Warranty
3-year KOHLER® engine and 1-year limited DK2 chassis
Feature
KOHLER Command PRO CH270 7 HP 208 cc engine.
Direct drive combo chipper shredder with dual carbide chip & quad hammer shredders.
Perfect for trees, branches, leaves and garden composting.
Extra-large hopper feed chute for branches and brush.
Large feed chute for trees up to 3 in in diameter.
Drop stand and handy removable tow bar.
13.75 in x 5.25 in (W) ATV-locking wheels perfect for off-road towing up to 15 mph.
Removable key shut off.
Includes 3-year KOHLER and 1-year limited DK2 warranty.
Package Size
LxWxH (inch): 43x23x22
Weight (lb): 198.42
A forklift or equivalent is required for unloading.
